6X6 2in. Elevated Column Base HDG
$179.22
Engineered for durability and versatility, the elevated column base is a reliable solution for both hollow columns and solid sawn posts. It features a 2-inch elevation, ensuring proper accommodation for moisture barriers and surface material while maintaining a 1-inch standoff for effective moisture management. The design incorporates flexible anchorage options, with four corner holes for screw-down installation to wood, or a central hole for anchoring to concrete, enhancing adaptability for various construction environments. Constructed from 12-gauge cups and 7-gauge base and tube steel, along with hot-dip galvanization, this base offers exceptional corrosion resistance, making it ideal for use in exterior settings and with treated wood applications.
Description
The Simpson Strong-Tie® ECB elevated column base for hollow columns or solid-sawn posts makes it easy to install waterproofing material on stacked balconies in multi-family buildings. It’s the only post base available off the shelf that features a 2-in. standoff, providing enough room for moisture barrier material and a thin finish surface while still allowing for the 1-in. code-required standoff to prevent post decay. There are two model sizes available, suitable for either 6×6 or 8×8 posts.
Additional information
| Weight | 4.91 lbs |
|---|---|
| Dimensions | 5 × 5 × 5 in |
| Standoff Height | 2 in |
| Standoff Clearance | 1 in |
