ADHESIVE RETAINING CAP 1-1/16IN HOLE DIA
$13.51
Engineered for versatility, the Simpson Strong-Tie adhesive retaining cap is specially designed for use with a hole diameter of 1-1/16 inches, making it ideal for various anchoring applications. With a unique slit that allows the insert to pass through while containing adhesive, this cap ensures a clean and efficient installation process in overhead, upwardly inclined, and horizontal orientations, as well as deep embedments. It effectively centers threaded rods or rebar dowels during insertion, enhancing both accuracy and reliability. Compatible with any Simpson Strong-Tie anchoring adhesive, it serves as an essential component for anchoring tasks in demanding environments.
Description
Simpson Strong-Tie® ARC adhesive retaining caps make overhead and horizontal anchor installations easier by preventing the adhesive from running out of the hole. They also center the rod or rebar dowel in the hole, making them ideal for applications where precise anchor placement is required. Adhesive retaining caps are not designed to support the weight of the anchor, so it’s advisable in overhead installations to provide an adequate means of anchor support during cure time. ARC retaining caps may be used in conjunction with our Piston Plug Delivery System
Additional information
| Weight | 0.22 lbs |
|---|---|
| Dimensions | 5 × 5 × 5 in |
| Drill Bit Diameter | 1-1/16 in |
| Depth | 1.56 in |
