HURRICANE TIE ZMAX
$4.87
Engineered for strength and durability, this hurricane tie from Simpson Strong-Tie is crafted from 18-gauge steel to provide robust support against wind and seismic forces. The tie plays a critical role in forming a continuous load path, enhancing the structural integrity of your projects. With a seat width of 1-9/16 inches and ZMAX galvanization, it offers superior corrosion resistance, making it an excellent choice for exterior and treated-wood applications. This combination of features ensures your constructions are safeguarded against harsh conditions while maintaining long-lasting performance.
Description
The H10A series holds the rafter or truss on both sides for higher uplift applications with embossments that add stiffness in crucial areas for improved performance. These U-shaped hurricane ties provide faster installation than using two single-sided ties. H10A models come with optional fastener holes to connect roof blocking to the top plate. Slots allow field bending up to a maximum pitch of 6:12 to accommodate angled blocking.
Additional information
| Weight | 0.41 lbs |
|---|---|
| Dimensions | 5 × 5 × 5 in |
| Depth | 5 in |
| Seat Width | 1-9/16 in |
