Simpson Strong-Tie FC82-5/118-R25 CFS RIGID CLIP 2 X 8 X 5 10GA 25PAK (1/each)
$186.31
Engineered for superior stability and strength, this fixed-clip connector is designed specifically for use with 8-inch studs, making it an essential component for robust framing applications. Constructed from 10-gauge steel and galvanized for enhanced corrosion resistance, it features strategically placed embossments that bolster its strength and stiffness in critical load directions, allowing for effective weld application at both ends. The prepunched anchor holes accommodate a range of fastening methods, including concrete screws and powder-actuated fasteners, ensuring versatile installation options. Whether you’re tackling a large construction project or a smaller renovation, this fixed-clip connector offers the reliability and performance needed for long-lasting structural integrity.
Description
Ideal for high-seismic areas, Simpson Strong-Tie® FC connectors are the optimal solution for fixed-clip bypass framing. FC clips are often welded to the structure in high-seismic zones, but they also feature anchorage holes so that concrete screws or powder-actuated fasteners can be used to attach the clip to the structure. In addition to its anchorage versatility, the FC clip features prepunched screw holes for the framing attachment, eliminating the need for predrilling holes or worrying that fastener placement doesn’t match the designer specifications. FC connectors are manufactured using heavy-duty 10- or 12-gauge steel to provide exceptional resistance to in-plane seismic load.
Additional information
| Weight | 45.375 lbs |
|---|---|
| Dimensions | 5 × 5 × 5 in |
| Length | 8 in |
| Depth | 5 in |
