Simpson Strong-Tie SCS62-5/118-KT25 Slide Clip 2x6x5 10 ga 25 PAK w/Screws (1/each)
$200.89
The SCS 2 in. x 6 in. x 5 in. Seismic Bypass Framing Slide Clip from Simpson Strong-Tie is crafted from robust 10-gauge steel, making it an excellent choice for structures requiring enhanced seismic performance. This dual-function clip features precision-located ribs to ensure strength and ductility during use, while the included galvanized screws allow for a full 1 inch of vertical deflection, accommodating necessary adjustments. The thoughtful design includes No-Equal stamps next to slide slots for clear guidance on screw placement, ensuring ease of installation. With corrosion-resistant properties thanks to its G90 galvanization, this framing slide clip is ideally suited for applications that require durability and reliability in challenging environments.
Description
The Simpson Strong-Tie® SCS is a hybrid clip designed specifically to allow both slide-clip or fixed-clip applications in areas of high seismic activity. Everything about the SCS clip — from its heavy-duty steel manufacturing to its strategically placed darts to the location of its fastener slots and holes — has been engineered to provide exceptional resistance to in-plane seismic loads. Backed by our real-world, full-scale cyclic testing, the SCS seismic clip delivers the highest seismic loads in the industry. Slide-clip testing shows that attachment at the first slot is most critical to in-plane capacity, the SCS is designed to accommodate two large washer screws (included) at the first slot attached to the stud. The hole types and locations maximize the SCS clip’s versatility, with three prepunched oblong slots for slide-clip applications and a pattern of round holes allowing fixed-clip options to meet a range of load needs.
Additional information
| Weight | 37.34 lbs |
|---|---|
| Dimensions | 5 × 5 × 5 in |
| Depth | 6 in |
| Width | 6 in |
